Technical Characteristics
The special hydraulic chassis for the rotating drill with extensible crawler is providedwith the excellent stability and is convenient to transport; the imported Cumminsturbo-supercharged engine (meeting EU-III standard) is powerful,and has sufficientpower reserve, which can be operated in plateau, its noise and emission meet thenational standards: the constant power and the best output enable the completemachine to function at its best:
The load-sensing technique is used in the hydraulic system to make it more efficientand save more energy:
The patented parallelogram articulation mechanism can work in a large area, the drillmast, which is designed in box structure and made of the materials with high strength,has good rigidity and anti-distortion, guaranteeing the drilling accuracy, the hinge isprovided with the bearing exempt from lubrication, and can work freely,the slag canbe discharged in any angle due to 360° lifting and revolving;
The intellectual controlling system, CAN bus and PLC with self-intellectual propertyright are used, including the automatic and manual regulation of the perpendicularityof the drill mast, automatic display of the drilling depth, automatic rotationpositioning control, and intellectual fault diagnosis control;
The machine adapts single row rope for main winch to figure out the wear of steelrope and extend the life-span, and high reliability;
With infrared camera for observing main winch, manipulator can observe the state ofsteel rope at day and night in cab;
Standard centralized lubricating system, allowing easier maintenance;
The complete machine has passed CE certification of T ü V Rheinland group.
