Technical Characteristics
It adopts dedicated H-type hydraulic retractable crawler chassis andlarge diameter slewing bearing, chassis with swing legs to aiddisassemble;
Imported Cummins electric control turbo-supercharged engine is used,itcomplies with Euro III emission standed, in addition, it has strongpower, which is sufficient to satisfy the construction on the plateau, itsnoise is up to the national standard;
It adopts the single-rope main winch structure, the main winch rope atfull drilling depth 132 m status can meet single-rope winding,effectivesolution to line tangle problem, to greatly prolong the service life ofsteel wire rope;
Normal mode and entering-rock mode of unit head are available foroperation in soil and rock to improve the construction efficiency;
Power head with automatic rotation, in normal mode and entering-rockmode rotating speed continuously adjustable;
It is equipped with a centralized lubrication system as standardconfiguration, maintenance is easy.
